KTS 590 – ECU Diagnostic tool for all current and future vehicles, with multimeter and oscilloscope

KTS 590 | Bosch Mobility Aftermarket

KTS 590

KTS 590 ports and conncetions | Bosch Mobility Aftermarket

KTS 590 ports and conncetions

KTS 590 Scope of delivery | Bosch Mobility Aftermarket

KTS 590 Scope of delivery

KTS 590 | Bosch Mobility Aftermarket
KTS 590 ports and conncetions | Bosch Mobility Aftermarket
KTS 590 Scope of delivery | Bosch Mobility Aftermarket

The KTS 590 communication module ensures the most advanced ECU diagnosis for Ethernet-based (DoIP – Diagnostics over Internet Protocol) vehicle interfaces with features that will significantly enhance your workshop’s output.

With access to the latest measuring technology, technicians can efficiently test and measure all sensor and actuator signals, and quickly and effectively evaluate voltage, resistance and current. As the most up-to-date control unit around, it is the future-proofed choice.

More Information

  • Built-in 2-channel oscilloscope: Benefit from real-time viewing of electrical signal variation for highly precise testing of complex electrics
  • Built-in 2-channel multimeter: Locate and fix electrical issues quickly
  • Fully PassThru compliant: Access and reprogram vehicle manufacturer control unit software for efficient daily workshop routines
  • Parallel diagnosis: The module can communicate with up to three CAN and K-Line interfaces simultaneously enabling fast and productive diagnosis
  • 100 m-range Bluetooth connectivity: Ultimate convenience – increase your workshop coverage and increase your productivity
  • Supports Bosch Easy Connect and other Bosch vehicle-specific adapters: Easily extend diagnostic capabilities with choice of vehicle-manufacturer-specific non-OBD cables
  • Optimally designed for ESI[tronic] software (purchased separately): Enjoy intelligent diagnostics, trouble-shooting and support for rapid repair and maintenance
  • Works on any Windows PC with ESI[tronic] installed and licensed: The versatile way to control diagnosis and repair within your workshop



KTS 590 2-channel multimeter & 2-channel oscilloscope
KTS 590
Connections to PC
2-channel multimeter & 2-channel oscilloscope
USB 2.0, Bluetooth® Class 1
KTS 590
Weight
2-channel multimeter & 2-channel oscilloscope
approx. 0.5 kg
KTS 590
Operating voltage
2-channel multimeter & 2-channel oscilloscope
8V DC-28V DC
KTS 590
Power consumption via vehicle battery or power supply
2-channel multimeter & 2-channel oscilloscope
< 10 Watt
KTS 590
Dust and water protection
2-channel multimeter & 2-channel oscilloscope
IP53
KTS 590
Multimeter bandwidth
2-channel multimeter & 2-channel oscilloscope
100 kHz
Oscilloscope sampling rate 20 MS/s
Oscilloscope sampling rate
Vehicle protocols
20 MS/s
ISO 15031, ISO 22900,
SAE J2534-1 and -2
(PassThru), ISO 9141-2
(K and L), SAE J1850
VPW and PWM,
CAN High Speed ISO 11898,
ISO 15765-4 (OBD),
CAN Single Wire, CAN
Low Speed, ISO 13400
(Diagnostics over IP),
and other vehicle-specific
protocols
Oscilloscope sampling rate
Dimensions
20 MS/s
125 x 44 x 180 mm
(W x H x D)
Oscilloscope sampling rate
Operating temperature
20 MS/s
5 °C – 40 °C
  • OBD connection cable (1.5 m)
  • Power supply unit
  • Test lead/probe set
  • Measuring lead (red /black) only KTS 590
  • Tapping clamp black
  • Test tip red
  • USB connecting cable (3m)
  • Mounting kit
  • Trolley mounting parts set
  • Bluetooth® USB adaptor
  • Operating manual
  • Storage case
BMW 20-pin
1 684 463 631
Daewoo/GM/Holden 12-pin
1 684 463 632
Fiat-Group 3-pin
1 684 463 613
Honda 3/5-pin
1 684 463 634
Hyundai/Mitsubishi 12-pin
1 684 463 638
KIA 20-pin
1 684 463 636
Mazda 25-pin
1 684 463 637
Nissan 14-pin
1 684 463 639
OBD-Adapter PKW-NKW 24/12V
1 684 463 650
Renault PkW 12-pin
1 684 465 582
Toyota “Avensis” without pin 1 and 9
1 684 463 686
Toyota 17-pin
1 684 463 642
Toyota 23-pin
1 684 463 643
VW/ Audi 2pin
1 684 463 611
Suzuki 6-pin
1 684 463 641
Mercedes Benz 14-pin (Sprinter, Atego)
1 684 463 594
SD-Adapter Set 1 in case
(BMW, Citroën, Peugoet, Fiat, Lancia, Alfa, Renault)
1 687 011 517
SD-Adapter Set 2 in case
(BMW, Citroën, Peugoet, Fiat, Lancia, Alfa, Toyota, VW, Audi, MB)
1 687 011 516
Connection line OBD cable to Uni 4 for vehicle-specific adapters with banana sockets
1 684 463 539
USB Bluetooth Extension 1.8m for Bluetooth USB Adapter
1 684 465 564
USB Bluetooth Extension 3.0m for Bluetooth USB Adapter
1 684 465 565
Bracket for Bluetooth USB adapter
1 681 312 005
Test cable set
1 687 011 208
OBD adapter box with OBD plug and additional OBD socket
1 684 462 514
AC / DC current tongs 100/600 A with banana plug
1 687 224 864
